71M6533- DB Demo Board User’s Manual
0x40
0x32
0x4A
0x3A
0x52
0x42
Vah_B
Whi_C
Whe_C
VARhi_C
VARhe_C
VAh_C
Total VA hours in element 1
Total Watt hours consumed through element 2
Total Watt hours generated (inverse consumed) through element 2
Total VAR hours consumed through element 2
Total VAR hours generated (inverse consumed) through element 2
Total VA hours in element 2
Table 1-8: MPU Accumulation Output Variables
1.10.3 USEFUL CLI COMMANDS INVOLVING THE MPU AND CE
Table 1-9 shows a few essential commands involving data memory.
Command
)1=2
)A=+2080
)9=+6000
)2F??
MR2.1
MR1.2
RI5=26
RI5=6
]U
Description
Clears the accumulators for Wh, VARh, and VAh by setting bit 1 of the CONFIG register.
Applies the value 208A to the IMAX register
Applies the value 600V to the VMAX register
Displays the total accumulated imported Wh energy
Displays the current RMS voltage in phase A
Displays the current RMS current in phase B
Disables the emulator clock by setting bit 5 in I/O RAM address 0x05. This command will
disable emulator/programmer access to the 71M6533.
Re-enables the emulator clock by clearing bit 5 in I/O RAM address 0x05.
Stores the current CE RAM variables to flash memory. The variables stored in flash memory
will be applied by the MPU at the next reset or power-up if no valid data is available from the
EEPROM.
Table 1-9: CLI Commands for Data Memory
Page: 33 of 75
`
